Link-Belt 218 HSL Crawler Crane
1. Overview
The Link-Belt 218 HSL is a lattice boom crawler crane known for its robust construction and dependable performance in heavy-duty lifting operations. This crane is widely used in construction, infrastructure, energy, and industrial applications, as well as drilling rig support. With a 110-ton lifting capacity and advanced engineering, it remains a reliable choice for various lifting tasks.
2. Link-Belt: A Legacy of Innovation
Link-Belt began in 1874 with William Dana Ewart’s invention of the Link-Belt drive chain. Over the years, the company has evolved into a leading manufacturer of cranes and heavy equipment, known for its innovation and commitment to customer satisfaction.
3. Key Features and Applications
- Construction: Lifting steel beams, precast concrete, and large machinery.
- Infrastructure: Used in bridge construction, road building, and highway projects.
- Energy Sector: Supports power plant, wind farm, and oil & gas facility construction.
- Industrial Applications: Moves heavy machinery in factories and warehouses.
- Drilling Rig Support: Assists in assembling and disassembling drilling rigs with loads up to 104,000 lbs.
4. Technical Specifications
| Specification | Value |
|---|---|
| Maximum Capacity | 110 tons |
| Maximum Boom Length | 230 ft |
| Maximum Jib Length | 140 ft |
| Maximum Tip Height (Fixed Jib) | 279 ft |
| Engine | Cummins QSB 6.7 Tier 4 Final |
| Horsepower | 270 hp @ 2000 rpm |
| Maximum Hoist Pull | 44,565 lbs |
| Hoist Speed | 356 ft/min |
| Counterweight | 62,820 lbs Upper + 22,200 lbs Lower |
| Working Weight | 192,735 lbs |
| Main Transport Load | 99,960 lbs |
5. Operator Cab and Safety Features
5.1 Operator Cab
- Spacious and Ergonomic Design: Reduces fatigue and enhances productivity.
- Wide Visibility: Provides a clear view of the worksite.
- Fully Adjustable Seat and Console: Improves operator comfort.
5.2 Safety Features
- Rated Capacity Limiter: Helps operators execute lifts safely.
- Rearview Camera: Enhances visibility in confined spaces.
- Counterbalance Valves: Prevent accidental load drops.
- Wet-Style Multi-Disc Brake System: Provides smooth load control and extended service life.
- Counterweight Removal System: Simplifies transport and setup.
6. Real-World Performance and User Reviews
6.1 Operator Reviews
- Operators praise the crane’s stability and visibility, especially in drilling rig support applications.
- The counterweight system is commended for its ease of use.
- Cab layout and control repositioning improve comfort and reduce fatigue.
6.2 Real-World Applications
- Drilling Rig Support: Assists in lifting up to 104,000 lbs.
- Bridge Construction: Used in highway projects for beam placement.
- General Construction: Moves heavy equipment like generators and pumps.
7. Next-Generation Model: Link-Belt 218|V
The 218|V is an upgraded version of the 218 HSL, offering:
- 5% Increased Lifting Capacity
- New Cummins QSB6.7 Stage V Engine (Higher horsepower and stricter emissions compliance)
- Enhanced Operator Comfort: Redesigned cab, repositioned pedals, and improved LMI display.
8. Pricing and Dealers
The cost of a used Link-Belt 218 HSL varies depending on year, condition, and features. Prices typically range from $275,000 to over $900,000.
Authorized Dealers in Indiana:
| Dealer Name | Location | Offerings |
|---|---|---|
| RUDD - Evansville | Evansville, IN | Rental, Used Equipment, Parts, Service |
| Construction Machinery Company | Jeffersonville, IN | New & Used Equipment, Parts, Service |
| Reco Equipment Inc. | Fort Wayne & Indianapolis, IN | New & Used Equipment, Parts, Service |
9. Conclusion
The Link-Belt 218 HSL is a highly capable crawler crane with proven reliability, advanced safety features, and high lifting capacity. While the newer 218|V model offers improved performance, the 218 HSL remains an excellent choice for those seeking a dependable, cost-effective crane.
